Rexroth 4WEH22E7X/6EG249K4 Directional Control Valve

Name: Rexroth 4WEH22E7X/6EG249K4 Directional Control Valve
Brand: G. S. HYDRAULICS
Price: 10200 INR
Availability: InStock

Price 10200 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Rexroth 4WEH22E7X/6EG249K4 Directional Control Valve Specification

Temperature Range
-20C to +80C

Efficiency
High Performance, Low Pressure Loss

Operating Pressure
Up to 350 bar

Flow Rate
Up to 315 L/min

Sealing Type
NBR (Nitrile Rubber) Seals

Application
Industrial Hydraulic Systems, Machine Tools, Mobile Equipment

Features
Wet-pin AC solenoid, Manual override, Robust construction

Accessories
Mounting bolts, Sealing rings, Electrical connectors

Power Source
Electric

Mounting Type
Subplate Mounting

Connectivity Type
Connector as per DIN EN 175301-803

Usage
Industrial

Body Material
Steel

Type
Hydraulically Operated Directional Control Valve

Structure
Spool Valve

Force
Electromagnetic

Product Type
Control Valves

Speed
High Response

Color
Black

Voltage
24V DC

Warranty
Yes

Surface Protection
Phosphate coated

Protection Class
IP65 with standard connector

Model Number
4WEH22E7X/6EG249K4

Viscosity Range
2.8 to 500 mm2/s

Response Time
< 50 ms

Fluid Type
Mineral oil as per DIN 51524

Number of Positions
3

Size
22 mm

Actuation
Solenoid Operated

Weight
Approx. 18 kg

Leakage
Maximum 60 cm3/min at 100 bar

Port Connection
ISO 4401 size 10

Spool Symbols
E (Spring return, 4-way, 3 position)

Coil Duty
Continuous (100% ED)

Rexroth 4WEH22E7X/6EG249K4 Directional Control Valve Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Rexroth 4WEH22E7X/6EG249K4 Directional Control Valve

Valve Size	1.5 inch
Material	Alloy Steel
Brand	Rexroth
Model Name	4WEH22E7X/6EG249K4
Colour	Black (Base)

The Rexroth 4WEH22E7X/6EG249K4 is a high-performance, solenoid-operated directional control valve designed for precise hydraulic flow control in industrial applications.

Reliable Hydraulic Performance

The Rexroth 4WEH22E7X/6EG249K4 offers consistent directional control for industrial hydraulic applications. Its electromagnetic force and high response speed ensure efficient system operations. Engineered for low pressure loss and long-lasting use, it stands out with its robust steel body and phosphate coating for enhanced durability, making it a preferred solution for heavy-duty environments.

Advanced Features for Versatile Applications

This spool valve integrates a wet-pin AC solenoid, manual override, and superior sealing with NBR materials. It is IP65 rated, supporting mineral oil fluids with viscosities between 2.8 and 500 mm2/s. Compatible with ISO 4401 size 10 connections and designed for subplate mounting, installation and maintenance are straightforward for a variety of industrial systems.

FAQ's of Rexroth 4WEH22E7X/6EG249K4 Directional Control Valve:

Q: How does the Rexroth 4WEH22E7X/6EG249K4 valve operate within a hydraulic system?

A: This valve uses solenoid actuation to control fluid flow direction. With a 4-way, 3-position E spool and spring return, it enables swift transitions and precise control, supporting efficient operations in hydraulic circuits.

Q: What fluid types and viscosity ranges is this directional control valve suitable for?

A: The valve is designed for use with mineral oil as specified by DIN 51524. It handles viscosity ranges from 2.8 to 500 mm2/s, ensuring performance across a wide array of standard hydraulic fluids.

Q: When should the Robus Rexroth valve be considered for installation in industrial systems?

A: You should choose this valve for applications needing high flow (up to 315 L/min), rapid response (less than 50 ms), and robust performance under pressures up to 350 bar. It's ideal in environments where reliability and efficiency are critical.

Q: Where can the Rexroth 4WEH22E7X/6EG249K4 be mounted and what connections does it support?

A: Designed for subplate mounting, it uses ISO 4401 size 10 port connections, making it compatible with widely adopted industrial mounting standards and systems.

Q: What are the primary advantages of using this particular Rexroth valve?

A: The main benefits include high performance, low pressure loss, rapid response, and robust construction. The IP65 rating, phosphate coating, and long service life make it suitable for demanding applications with minimal maintenance.

Q: How is the manual override feature used in this spool valve?

A: The manual override allows operators to actuate the valve manually during maintenance or emergencies, ensuring flexibility and operational safety without requiring electrical power.

Q: What is included with the Rexroth 4WEH22E7X/6EG249K4 upon purchase?

A: Each valve package typically includes mounting bolts, sealing rings, electrical connectors, and a connector conforming to DIN EN 175301-803, simplifying installation and integration.
